Description
35-Pin MAN Harness Connector Set – Engine & Gearbox Loom Repair Solution
The 35-Pin MAN Harness Connector set is designed for professional repair of MAN truck wiring looms across the TGA, TGS, TGX, and selected F2000/M2000 ranges. This round connector style is commonly used between the engine harness, gearbox harness, and chassis loom. When worn, burnt, or oil-contaminated, replacing it with a new 35-Pin MAN Harness Connector restores proper electrical communication and prevents costly diagnostic time.
Where the 35-Pin MAN Harness Connector Is Used
On MAN trucks, this connector is found in several critical areas, including:
-
Gearbox control wiring
-
Engine-side auxiliary sensor clusters
-
MAN TipMatic gearbox harnesses
-
Chassis-side powertrain interfaces
-
Loom junctions near the transmission bellhousing
The 35-Pin MAN Harness Connector carries signals such as:
-
Gear selector position
-
Input/output speed sensor data
-
Clutch actuator feedback
-
Engine auxiliary control lines
-
CAN communication pathways
A damaged connector can trigger gearbox faults, limp mode, CAN errors, or intermittent loss of communication with the ECU.
Common Symptoms of 35-Pin Connector Failure
Technicians frequently encounter:
-
Gearbox warning indicators on MAN TipMatic systems
-
Loss of communication with transmission ECU
-
Failed or intermittent actuator signals
-
High resistance caused by corroded terminals
-
Oil contamination breaking down insulation
-
Broken locking rings causing loose connection
Replacing the old connector with a new 35-Pin MAN Harness Connector often resolves these problems without expensive module replacement.
What’s Included in the Connector Kit
This complete repair set includes:
-
1 × 35-Pin Male MAN Connector Body
-
1 × 35-Pin Female MAN Connector Body
-
Full set of male terminals
-
Full set of female terminals
-
Locking ring and sealing grommets
-
Weather-resistant housings
Each 35-Pin MAN Harness Connector is manufactured using high-temperature polymers and corrosion-resistant terminals suitable for harsh commercial vehicle environments.
Compatibility
This connector fits:
-
MAN TGA
-
MAN TGS
-
MAN TGX
-
MAN F2000 / M2000 (depending on harness type)
-
MAN TipMatic gearbox looms
-
MAN D20, D26, and D28 engine harnesses
If your truck uses a similar 35-way round connector, this replacement kit is the correct option.
Ideal Uses
Workshop technicians use the 35-Pin MAN Harness Connector for:
-
Rebuilding damaged wiring looms
-
Repairing engine-to-gearbox loom plugs
-
Replacing burnt, cracked, or melted connectors
-
Fixing loose, corroded, or broken terminals
-
Custom diagnostic harness construction
-
ECU and gearbox actuator test benches
Durability & Build Quality
This connector is built to withstand:
-
High vibration
-
Extreme engine-bay temperatures
-
Oil exposure
-
Moisture and dust
-
Long-term mechanical stress
Its secure locking system and heavy-duty polymer material ensure reliable operation in demanding truck environments.
